The Munter Hitch – How To Belay Without a Belay Device

This 'Munter Hitch' article is part of the book - The Trad Climber's Guide To Problem Solving.

VDiff trad climbing self rescue book

Uses:
- Belaying without a belay device
- Abseiling without a belay device
- Creating a releasable knot when escaping the belay

The munter hitch tends to 'kink' the rope when used for abseiling or belaying. It can also cause slight abrasion to the rope's sheath, especially if the leader falls.

It is a useful skill to know, but is not intended for long-term use.

drop belay device climbing

How To Tie a Munter (Italian) Hitch

Step 1
Clip the rope through a large, pear-shaped (HMS) screwgate. Smaller screwgates work too, but will make belaying more difficult.

Munter italian hitch rock climbing

Step 2
Twist a loop in the climber's end of the rope as shown.

How to tie an italian hitch rock climbing

Step 3
Clip the loop into the screwgate.

How to tie a Munter hitch rock climbing

Step 4
Clip the carabiner to your belay loop and fasten the screwgate.

Munter hitch belaying

Warning!
Make sure the brake strand is on the 'spine' of the screwgate. If the brake strand is on the 'gate' side, it could rub against the gate and potentially open it.

Italian hitch belaying

Step 5
Test the knot by pulling tight on either end of the rope. The knot should flip through the carabiner easily both ways.

Munter italian hitch rock climb belay

VDiff climbing self rescue book

Belaying With a Munter Hitch

Belaying with a munter hitch is similar to using an ATC: you must keep hold of the brake rope at all times. The main difference is that you 'lock-off' in the opposite direction (see below). This goes against a climber's natural reaction, so make sure to practise this technique well before using it.

When bringing up the second on a munter hitch, it's easier to belay directly from the anchor (if your anchor setup allows), rather than from your harness.

Italian hitch belaying top rope

To Lock Off
The Munter hitch creates a lot of friction. Depending on the situation (rope thickness, weight of climber, rope drag, etc..), it can be locked off in any direction. However, for maximum friction, you must hold the brake rope forward (so that both strands of rope are parallel to each other).

Munter hitch belaying

To Give Slack
Hold the brake rope loosely and pull through slack rope, similar to giving slack with an ATC.

Italian hitch belay

To Take In
Pull the brake rope so that the knot 'flips'. More rope can now be taken in by continuing to pull rope through forwards.

Munter italian hitch rock climb belay

To Lower
Lock the rope off in the maximum friction position described above. Slowly move the rope back and lower as you would with an ATC. It can be tricky to find the 'sweet spot', so make sure to move position slowly.

Munter italian hitch belaying

How To Tie-Off a Munter Hitch - The Munter-Mule-Overhand

Uses:
- Tying off a munter hitch when belaying or escaping the system.

Step 1
Form a loop in the brake-strand of rope as shown.

Munter-mule hitch rock climbing

Step 2
Feed a bight of the brake rope around the climber's rope and through the loop as shown.

Pull the knot tight, either by easing the climber's weight onto the rope if they are weighting it, or by pulling up on the climber's strand of rope if they're not weighting it. The munter hitch is now tied-off, but not backed-up (see next step).

Munter-mule hitch belaying

Step 3
To complete the knot, you must back it up. One way of doing this is to tie an overhand around the climber's strand of rope. To start, wrap the loop around the back of the rope.

Munter-mule hitch

Step 4
Then feed it back through as shown.

Munter-mule hitch climbing

Step 5
A carabiner completes the hands-free munter-mule-overhand.

Munter mule overhand knot

To Release
Unfasten the overhand knot Then pull forwards on the brake strand of rope until the knot pops free.

If the rope is weighted, you can expect a few centimetres of rope to slip through the munter hitch. Prepare for this by holding the brake strand tight with both hands.

Munter-mule hitch release

Munter Hitch Belaying - Top Tips

When using a small diameter rope, it's worth using two carabiners to increase belay friction.

Munter hitch belaying skinny rope

To belay the second with half ropes, you can treat them as one and tie them together in the same munter hitch. If you need to pull one rope through faster than the other, you should use two separate knots (see next tip) instead.

Munter hitch belay two ropes

To lead belay with half ropes, you'll need to use two separate screwgates with a munter hitch on each. This can be difficult at first, especially giving slack on one rope while simultaneously taking in the other. Practice well before you use this technique.

Munter hitch two rope belaying
